Drill Pipe
Thread Protectors
Product Information
Tool joint thread protectors will protect drill pipe, bits, stabilizers, collars, and all API type Spec 7 connection types. Provides connection face, thread, and ID from contact, impact and environmental hazards. Please choose the level of protection below
Light Weight Tool Joint (Gray)
The most economical way of protecting tool threads from environmental corrosion and point to point handling. Added polyethylene with molded ribs make this protector the most commonly used in the Petroleum Industry.
| Thread Type | Size Range |
|---|---|
| IF | 2" - 6-5/8" |
| REG | 2-3/8" - 7-5/8" |
| FH | 3-1/2" - 6-5/8" |
ALSO AVAILABLE IN; PAC, MAYHEW, H90, ALL-NC, LEFT-HAND
| Thread Type | Size Range |
|---|---|
| IF | 2-3/8" - 4-1/2" |
| REG | 2-3/8" - 8-5/8" |
| FH | 4" - 6-5/8" |
ALSO AVAILABLE IN: NC, SLH90, HT, XT, XTM, HTPAC
Heavy Weight Tool Joint (Black)
Molded from a copolymer blend, this protector withstands extreme handling from point to point and withstands utlraviolet degradation. Available in most API and High Torque tool joint configurations.
Pressed Steel Tool Joint
Our Pressed Steel protector line offers the most in maximum protection. Design criteria meets all API spec 7 requirements and exceeds the Industry standards. Available in all API configurations.
| Thread Type | Size Range |
|---|---|
| IF | 2-3/8" - 4-1/2" |
| REG | 2-3/8" - 8-5/8" |
| FH | 4" - 6-5/8" |
ALSO AVAILABLE IN: NC, AOH, HT, XT, XTM, H90
